- NORWEGIAN NS FLANGE
NS 2537 Flange
|
|
O.D. |
D |
d1 |
k |
t |
No |
size |
a |
b |
Hull i plate d3 |
approx. |
||
|
d1 |
Bolter |
d2 |
|||||||||||
|
|
mm |
mm |
mm |
mm |
mm |
|
|
|
mm |
mm |
kg/ea. |
||
|
DN |
Pipe |
Flange |
|
|
|
Bolts |
|
|
|
|
Weight |
||
|
200 |
219,1 |
340 |
246 |
295 |
38 |
8 |
M 20 |
|
23 |
|
29 |
224 |
12,3 |
|
250 |
273 |
395 |
290 |
350 |
38 |
12 |
M 20 |
|
23 |
|
29 |
278 |
16,0 |
|
300 |
323,9 |
445 |
342 |
400 |
38 |
12 |
M 20 |
23 |
|
29 |
|
330 |
18,1 |
|
350 |
|
505 |
374 |
460 |
38 |
16 |
M20 |
23 |
|
29 |
|
362 |
25,8 |
|
400 |
|
565 |
425 |
515 |
44 |
16 |
M24 |
28 |
|
34 |
|
413 |
35,7 |
|
-450 |
|
615 |
476 |
565 |
44 |
20 |
M24 |
28 |
|
34 |
|
464 |
38,7 |
|
500 |
|
670 |
528 |
620 |
44 |
20 |
M24 |
28 |
|
34 |
|
516 |
43,7 |
